2-Port 4K USB DisplayPort Cable KVM Switch

2-Port Cable KVMs

2-Port 4K USB DisplayPort Cable KVM Switch

Name: 2-Port 4K USB DisplayPort Cable KVM Switch
Brand: IOGEAR
SKU: GCS52DP
Price: 79.95 USD
Availability: InStock

2-Port Cable KVM DisplayPort

MPN: GCS52DP

UPC: 881317516411

$79.95

Easily switch between your two DisplayPort computers and control them with one monitor, one keyboard and one mouse. IOGEAR's 2-Port 4K USB DisplayPort Cable KVM Switch comes ready with built-in cables and is USB powered. Don't spend the extra money on features you don't need; this KVM offers the most efficient and affordable way to switch between your two DisplayPort computers.

2-Port 4K USB DisplayPort Cable KVM Switch

$79.95

Optimal Resolution to Get Things Done

The simple, yet robust 2-Port 4K USB DisplayPort Cable KVM Switch is designed with incredible DisplayPort 1.1 technology and high-definition resolutions up to 4K resolutions 4096 x 2160 @ 30Hz.

Built-in Remote Port Selector for Easy Port Switching

A built-in push button style remote port selector with 6ft cable provides most easy and flexible way for port switching and cable management.

Flexible and Expandable

The 2-Port 4K USB DisplayPort Cable KVM Switch is perfect for those who need to get the job done in the office and at home.

Need more USB ports? No Problem! Plug in a USB hub to expand your peripheral sharing between your computers.

Cinema 4K resolution up to 4096 x 2160 @ 30Hz
DisplayPort1.1 and HDCP compliant
Computer switching via remote switch button
Built-in cables
Plug-n-Play
Expand USB ports by adding a USB hub
Bus powered*
Supports 7.1 HD audio
Supports 2.1 analog audio

*May require external power supply via Micro-USB port

Console
DisplayPort monitor
Standard 104-key wired USB keyboard
Standard 2 or 3 button wired USB mouse
Speakers and Microphones (optional)

Computers
DisplayPort port
USB Type-A port
Audio ports (optional)

Operating Systems
Windows® 10, 11
Mac OS X 10.13+
Linux®, UNIX, and other USB supported systems

1 x GCS52DP DisplayPort KVM
1 x Manual

GCS52DP Quick Start Guide Download

Need more help with this product? Visit IOGEAR Knowledge Base

Function	GCS52DP
Computer Connections
Direct	2
Port Selection	Remote Pushbutton (6ft)
Console Connectors
Monitor	1 x DisplayPort
Keyboard	1 x USB Type A
Mouse	1 x USB Type A
Audio	1 x 3.5mm Mini Stereo Jack (Green)
Microphone	1 x 3.5mm Mini Stereo Jack (Pink)
CPU Connectors
Monitor	2 x DisplayPort
Keyboard & Mouse	2 x USB 2.0 Type A
Audio	2 x 3.5mm Mini Stereo Jack
Microphone	2 x 3.5mm Mini Stereo Jack
Connectors
USB	1 x USB 2.0 Mouse Port
LEDs
KVM	2 x White
Emulation
Keyboard	N/A
Mouse	N/A
Video Resolution	up to 4096 x 2160 @30Hz
Environment
Operation Temperature	32~120F (0~50C)
Storage Temperature	-4~144F (-20~60C)
Humidity	0~80% RH, Non-condensing
Housing
Case	Plastic
Cable Length	KVM cables: 48" (121.92cm); Remote Switch: 72" (182.88cm)
Power Consumption	DC 5V, 6.5W

Dimensions	GCS52DP
Unit Dimensions
Height	3.375" (8.57cm)
Length	3.25" (8.27cm); KVM cables: 48" (121.92cm); Remote Switch: 72" (182.88cm)
Depth	1.06" (2.69cm)
Unit Package Dimensions
Height	8.875" (22.5cm)
Width	6.125" (15.56cm)
Depth	2.18" (5.54cm)
Master Carton
Height	6.75" (17.15cm)
Width	15.25" (38.74cm)
Depth	8" (20.3cm)
Master Carton Qty.	6
Weight
Master Carton Wt.	7.55lb (3.44kg)
Unit Pack Wt.	0.90lb (0.41kg)
Unit Wt.	0.90lb (0.41kg)

3 Year Limited Warranty
