4-Port 4K Dual View DisplayPort KVMP with USB 3.0 Hub and Audio

4 Port Desktop KVMs

4-Port 4K Dual View DisplayPort KVMP with USB 3.0 Hub and Audio

Name: 4-Port 4K Dual View DisplayPort KVMP with USB 3.0 Hub and Audio
Brand: IOGEAR
SKU: GCS1944
Price: 699.95 USD
Availability: InStock

2-Port DisplayPort Dual View TAA Compliant

MPN: GCS1944

UPC: 881317516688

$699.95

Maximize your high-end dual DisplayPort workstations by connecting them to the 4-Port 4K Dual View Display Port KVMP. Experience 4K Cinema resolutions along with rich bass and 7.1 surround sound while switching between both computers and sharing two USB 3.0 peripherals with the push of a button.

4-Port 4K Dual View DisplayPort KVMP with USB 3.0 Hub and Audio

$699.95

Dual View for better visual experience

Connect two Cinema 4K DisplayPort monitors to your desktop or laptop to experience superior screen, image, and video quality. GCS1944 delivers a 4K resolution -up to 4096x2160@60Hz on each monitor. Now the desktop can extend from each connected computer for better viewing and to handle more tasks.

Built-in USB3.0 peripheral sharing

Control/share two USB 3.0 peripherals between two computers at up to 5Gbps data transfer speed. In addition, the USB peripheral can be separated from the KVM port switching, so when one computer is working with the connected USB device, user can switch to the other computer for other tasks without causing issues.

Convenient Switching Methods

There are 3 ways for GCS1944 Port switching. Hotkeys, pushbuttons on the front panel and mouse wheel button, pick the way best fit for your needs.

Up to Quad View when daisy-chaining two GCS1944 together

Tackle large projects and double your desktop viewing space by adding a second 4-Port KVMP (GCS1944). Expand your workstations to accommodate up to four Cinema 4K DisplayPort monitors.

Maximize your high-end multi-monitor workstation with superior video resolution
Share dual Cinema 4K DisplayPort monitors (4096 x 2160 @60Hz)
Operate 4 DisplayPort computers with 1 keyboard, mouse, and 2 monitors
Add another GCS1944 to expand up to four 4K monitors
DisplayPort 1.2 compliant, HDCP compliant
Allows independent switching of the KVM, USB, and audio devices
Control/share USB3.0 peripherals between 4 computers; save money on duplicate devices
Work on computer "A" without interrupting USB peripheral connectivity on computer "B"
SuperSpeed 5Gbps transfer rate
MST (Multi-Stream Transport)¹
DP++ supports HDMI and DVI output²
Computer selection via front panel pushbuttons, hotkeys, or mouse³
Supports 7.1 HD audio through DisplayPort⁴
Full bass response for high quality 2.1 channel audio
Mouse emulation or bypass feature supports most mouse drivers and multifunction mice
Multi-platform support – Windows®7, Windows 8.1, Windows 10, Mac OS®, and Linux®
Multilingual keyboard mapping supports English, French, and German keyboards
Mac® keyboard support and emulation⁵
RS-232 Commands⁶
Auto-Scan Mode to monitor all computers
Power on detection
Hot pluggable
Firmware upgradable
Includes all KVM and audio cables

¹MST requires two monitors capable of DisplayPort 1.2 daisychaining, or use of an external DisplayPort MST Hub. PC Source must be DisplayPort 1.2 compliant. A DisplayPort 1.1a monitor can be the last monitor in a DP1.2 chain
² Dual-Mode DisplayPort (DP++) requires active HDMI and DVI adapters for most display setups.
³ Mouse port switching supported alongside mouse emulation mode using a USB 3-button mouse wheel
⁴ HD audio through DisplayPort cannot be switched independently
⁵ PC keyboard combinations emulate Mac® keyboards.
⁶ DB9 to RJ-45 cable not included.

Console
2 x DisplayPort compatible monitors
Standard 104 key wired USB keyboard
Standard 2 or 3 button wired USB mouse
Microphone and speakers (optional)
Computer
2 x DisplayPort ports
Type A USB port
Audio ports (optional)

*Use with video adapter may change performance

1 x 4-Port 4K Dual View DisplayPort KVMP Switch with USB 3.0 and Audio
8 x DisplayPort Cables (5ft.)
4 x USB 3.0 Cables (6ft.)
4 x Audio Cable Set (6ft.)
1 x Power Adapter
1 x Manual

GCS1944 Product Manual Download

GCS1944 Quick Start Guide Download

GCS1944 RS232 Manual Download

GCS1944 Firmware V 1.1.103 Download

Release Date: 10/21/21

Windows 7 32-bit
Windows 7 64-bit
Windows 8.1 32-bit
Windows 8.1 64-bit
Windows 10 32-bit
Windows 10 64-bit

Need more help with this product? Visit IOGEAR Knowledge Base

Function	GCS1944
Computer Connections
Direct	4
Daisy Chain or Cascading	4
Port Selection	Pushbuttons, Hotkey, Mouse (mouse port switching only works with 3-key USB mouse wheel in emulation mode), or RS-232 commands
Console Connectors
Monitor	2 x DisplayPort (Black)
Keyboard	1 x USB Type A (Black)
Mouse	1 x USB Type A (Black)
Audio	2 x 3.5mm Mini Stereo Jack (Green; Front and Rear)
Microphone	2 x 3.5mm Mini Stereo Jack (Pink; Front and Rear)
CPU Connectors
Monitor	8 x DisplayPort (Black)
Keyboard & Mouse	4 x USB 3.0 Type B (Blue)
Audio	4 x 3.5mm Mini Stereo Jack (Green)
Microphone	4 x 3.5mm Mini Stereo Jack (Pink)
Switches
F/W Upgrade	1 x USB Type B
Port Selection	4 x Pushbutton
Connectors
USB	1 x USB 3.0 Type A (Blue; Front), 1 x USB 3.0 Type A (Blue; Rear)
Serial	1 x RJ-45 (DCC)
LEDs
On Line	4 x Orange
Selected	4 x Orange
Audio	4 x Green
USB Peripherals	4 x Green
Emulation
Keyboard	USB
Mouse	USB
Video Resolution	4096 x 2160 @60 Hz (4K DCI)
Scan Interval	1~255 seconds (5 seconds default)
Power Consumption	DC 12V
Environment
Operation Temperature	0~40 C
Storage Temperature	-20~60 C
Humidity	0~80% RH, Non-condensing
Housing
Case	Metal

Dimensions	GCS1944
Unit Dimensions
Height	2.125" (5.39cm)
Length	13.9" (33.5cm)
Depth	6.125" (15.56cm)
Unit Package Dimensions
Height	9.5" (24.13cm)
Width	21.5" (54.61cm)
Depth	4.75" (12.07cm)
Master Carton
Height	10.5" (26.67cm)
Width	22.25" (56.5cm)
Depth	15.25" (38.74cm)
Master Carton Qty.	3
Weight
Master Carton Wt.	27.5lb (12.5kg)
Unit Pack Wt.	9lb (4.09kg)
Unit Wt.	3.55lb (1.61kg)

3 Year Limited Warranty
