4-Port 4K KVMP Switch with HDMI® Connection, USB 3.0 Hub, and Audio (TAA)

4 Port Desktop KVMs

4-Port 4K KVMP Switch with HDMI® Connection, USB 3.0 Hub, and Audio (TAA)

Name: 4-Port 4K KVMP Switch with HDMI® Connection, USB 3.0 Hub, and Audio (TAA)
Brand: IOGear
SKU: GCS1934H
Price: 399.95 USD
Availability: InStock

4-Port HDMI TAA Compliant

MPN: GCS1934H

UPC: 881317518941

$399.95

Connect four (4) HDMI-enabled powerhouse computers to a 4K HDMI-enabled monitor, a USB keyboard and mouse, and switch between them using IOGEAR's 4-Port 4K HD KVMP Switch. With an enhanced user-friendly operation and extended features, the 4-Port 4K KVM Switch provides the latest in HDMI technology's innovations. With EDID support, the KVM reads and remembers the monitor's parameters, eliminating change in video resolution when switching between connected computers.

4-Port 4K KVMP Switch with HDMI® Connection, USB 3.0 Hub, and Audio (TAA)

$399.95

Enhanced Audio Connectivity

Additional smart connectivity features turn your workstation into a convenient and easy-to-use powerhouse. With an extended Audio Mixing feature, add up to two (2) audio sources from a simple hotkey operation, allowing you to monitor each computer's activities without switching between sources. Watch video from the computer on port #1 while waiting for the notification that your system on port #2 is finished updating firmware.

Connectivity

Additionally, the Power On Detection feature ensures that this KVMP automatically connects to the next powered-on computer. The built-in USB 3.1 Gen1 ports allow SuperSpeed 5 Gbps data transfer rates and are backward compatible with USB 2.0 and USB 1.1 legacy devices.

Cinema 4K Clarity for Many Industries

The GCS1934H delivers clear image resolutions up to Cinema 4K (4096 x 2160) at a frame rate of 60Hz. The switch supports high-resolution graphics for the healthcare industry, engineering and design, mid-sized businesses, and the federal segment. The IOGEAR 4K HD KVMP Switch also enhances electronics applications in diagnostic, coding, software development, application design, and forensic analysis.

Convenient Switching Methods

Switch and access four () HDMI-enabled computers from a push-button on the front panel or hotkey combination on your keyboard. IOGEAR's 4-Port HD KVM Switch also offers the latest mouse port-switching functionality. Easily switch between connected computers by clicking the wheel button on your 3-button USB mouse. For those who need controlled access, this 4K HD KVM switch supports RS-232 commands.

Control 4 computers using a single keyboard, mouse, and 4K HDMI monitor
Superior video quality - Cinema 4K (4096 x 2160 @60Hz)
HDCP 2.2 compliant, HDMI 2.0, HDR Support
2-Port USB 3.1 Gen1 Hub with SuperSpeed 5Gbps transfer rate
Computer selection via front panel pushbuttons, hotkeys, mouse¹, or RS-232 command²
Independent switching of the KVM, USB, and audio
Mouse emulation or bypass feature supports most mouse drivers and multifunction mice
Support HD Audio
Audio Mixer Modes -Mixes up to two audio sources as audio output
Multi-platform support - Windows®7, Windows®8.1, Windows®10, Mac®, and Linux®
Multilingual keyboard mapping supports English, French, and German keyboards
Mac® keyboard support and emulation³
Auto Scan Mode to monitor all computers
Power On Detection
Hot pluggable
Firmware Upgradable
Support N-Key Rollover(NKRO) - permits collision - free keying

Note

¹ Mouse port switching supported alongside mouse emulation mode using a USB 3-button mouse wheel

² Supports RS-232 commands when the station slide switch is located to position s. DB9 to RJ-11 cable not included.

³ PC keyboard combinations emulate Mac® keyboards.

Console

HDMI compatible monitor
Standard 104 key wired USB keyboard
Standard 2 or 3 button wired USB mouse
Speakers (optional)

Computer

HDMI port
Type A USB port
Audio ports (optional)

*Use with video adapter may change performance

1 x 4-Port 4K HD KVMP Switch with USB 3.1 Hub and Audio Mixer
4 x HDMI Cables (6ft.)
4 x USB 3.0 Cables (6ft.)
4 x Audio Cable Set (6ft.)
1 x Power Adapter
1 x QSG

GCS1934H Product Manual Download

GCS1934H Quick Start Guide Download

GCS1934H RS232 Commands Manual Download

GCS1934H Firmware Download Version 1.1.103

NEW Firmware Version 1.1.103 can support Dual QHD Curved Monitor 5120x1440

Need more help with this product? Visit IOGEAR Knowledge Base

Function	GCS1934H
Computer Connections
Direct	4
Port Selection	Pushbutton, Hotkey, RS-232 and Mouse (mouse emulation enabled)
Console Connectors
Monitor	1 x HDMI Female (Black)
Keyboard	1 x USB 2.0 Type-A (Black)
Mouse	1 x USB 2.0 Type-A (Black)
Audio	2 x 3.5mm Speaker Audio Jack (Green)
CPU Connectors
Monitor	4 x HDMI Female (Black)
Keyboard & Mouse	4 x USB 3.1 Gen1 Type B (Blue)
Audio	4 x 3.5mm Audio Jack (Green)
Switches
Port Selection	Pushbutton
Power Connections	1 x DC 5V Jack
Connectors
USB	2 x USB 3.1 Gen 1 Type A (Blue, front and rear)
RS-232	RJ-11
LEDs
Mode
KVM	4 (Orange)
Audio	4 (Green)
USB Peripherals	4 (Green)
Emulation
Keyboard	USB
Mouse	USB
Scan Interval	5~99 seconds (5 seconds default)
Power Consumption	DC 5V: 2.535W: 54.5 BTU
Environment
Operation Temperature	0?40ºC
Storage Temperature	-20?60ºC
Humidity	0?80% RH, Non-condensing
Housing
Case	Metal, plastic
Video Resolution	4096 x 2160 @ 60Hz (Cinema 4K)

Dimensions	GCS1934H
Unit Dimensions
Height	1.69" (4.29cm)
Length	10.25" (26.03cm)
Depth	2.94" (7.47cm)
Unit Package Dimensions
Height	8.27" (21cm)
Width	12.8" (32.5cm)
Depth	4" (10.16cm)
Master Carton
Height	14.25" (36.2cm)
Width	17.5" (44.45cm)
Depth	12.69" (32.23cm)
Master Carton Qty.	6
Weight
Master Carton Wt.	32lb (14.5kg)
Unit Pack Wt.	5.2lb (2.36kg)
Unit Wt.	1.9lb (0.86kg)

3 Year Limited Warranty
