Docking Station

USB-C Triple Video Docking Station with 120 Watt Power Supply (TAA Compliant)

DisplayLink EOL TAA Compliant
MPN: GUD3C11

UPC: 881317517364

Sale price$259.95

IOGEAR TAA Compliant USB-C Triple Video Docking Station is designed to transform your USB-C laptop into a full-featured workstation that rivals a desktop.

USB-C Triple Video Docking Station with 120 Watt Power Supply (TAA Compliant)
USB-C Triple Video Docking Station with 120 Watt Power Supply (TAA Compliant) Sale price$259.95

Triple Video USB-C Docking Station Packed With Features

IOGEAR TAA Compliant USB-C Triple Video Docking Station is designed to transform your USB-C laptop into a full-featured workstation that rivals a desktop. The Dock is equipped with 11 port options to add devices like a full-sized keyboard and mouse, an external hard drive, printer, webcam, a speaker set, and more via a single USB-C cable. Connect up to three monitors* through the Triple Video Dock to expand your visual workspace.



Triple 4K Ultra-HD Monitor Setup

Enjoy the remarkable visual experience of 4K Ultra HD (UHD), at four times the resolution of standard HD. The Dock supports impressive, Cinema 4K quality on a single DisplayPort monitor to 4096 x 2160 @60Hz for enhanced enjoyment while watching videos, playing games, working and creating. Attach dual 4K UHD DisplayPort screens and add a third 4K UHD HDMI display for crystal clear images and video quality to 3840 x 2160 @60Hz across all three.


Extend Your Desktop with Multiple Monitors

Expand your productivity by connecting additional monitors to your USB-C or Thunderbolt 3™ laptop. Add up to three (3) displays on most USB-C and Thunderbolt 3 enabled devices. When using a USB-C notebook with three monitors, use your notebook screen as a fourth monitor for separate tasks.


Charge Up While Docked

Charge up your laptop through the Dock via the included power adapter and charge a connected USB-A device that requires more than 0.9A of power through the BC 1.2 port. The Triple Video Docking Station passes a maximum of 60W of power to charge the laptop.**


* Recommended for multiple monitor support, please install latest DisplayLink drivers for your USB-C or Thunderbolt 3 laptop. Latest approved drivers available in the Drivers, Firmware, and Software.

** Not all USB-C laptops can charge through their USB-C port.

*** Multiple monitor support for Apple M1 laptops will require latest DisplayLink drivers to function.



  • Dock and expand your USB-C laptop with 11 port options
  • Connect up to 3 HD 4K displays via 2 DisplayPorts, 1 HDMI port*
  • Keep your laptop charged with up to 60W Power Delivery
  • 2x DisplayPort++ 1.2 ports support dual displays to 4K @ 60Hz
  • 1x HDMI port with DP Alt Mode supports HD display to 4K @ 30Hz
  • 1x USB-C port offers fast data transfer rates to 5Gbps
  • 2x USB 3.0 ports with one BC1.2 fast charging port
  • 2x USB 2.0 ports; 1x Gigabit Ethernet port
  • 2x 3.5mm audio ports for a headphone and microphone
  • TAA Compliant

* Requires installation of DisplayLink driver

Host device requirements

  • USB-C 3.0 or 3.1(Thunderbolt 3 compatible) device with DP Alt Mode Support
  • USB-C with USB mode can only support up to 2 monitors

OS requirements

  • Windows 7/8/8.1/10/11
  • Mac OS X 10.10+
  • Chrome OS
  • Ubuntu
  • DisplayLink Driver installation  (http://www.displaylink.com/downloads)
  • Host computer USB-C port must support USB Power Delivery 2.0 for charging function

Notes for M1 Mac Users: For M1 Mac Users, please check DisplayLink website for latest Mac Displaylink driver:
http://www.displaylink.com/downloads/macos

  • 1 x GUD3C11
  • 1 x 120W AC power adapter
  • 1 x 3.3ft USB Type-C to Type-C cable
  • 1 x Quick Start Guide
  • 1 x Warranty card

Notes for M1 Mac Users: For M1 Mac Users, please check DisplayLink website for latest Mac Displaylink driver:
http://www.displaylink.com/downloads/macos

Need more help with this product? Visit IOGEAR Knowledge Base

FunctionGUD3C11
Upstream Port
USB-CUSB 3.1 Gen 1 5Gbps, with Power Delivery up to 60W
Downstream Port
Audio In1x 3.5mm audio port
Audio Out1x 3.5mm audio port
DisplayPort2x DisplayPort with up to 4K@60Hz (3840x2160)
Ethernet1x Gigabit Ethernet
HDMI1x HDMI with DP Alt Mode, supports up to 4K@30hz (3840x2160)
USB-A2x USB 3.0; 2x USB 2.0
USB-C1x USB 3.1 Gen 1
Power AdapterExternal 120W AC Adapter
Operating System Requirements
MacMac OS X 10.10+ ~ 10.13.3
WindowsWindows 7 / 8 / 8.1 / 10
Environment
Humidity
Operation Temperature
Power
Power Delivery Pass-ThruPower Delivery Pass-through up to 60W
ProtocolsHDCP 2.2, DisplayPort Alt Mode
DimensionsGUD3C11
Unit Dimensions
Height3.54" (9cm)
Length8.86" (22.5cm)
Depth1.18" (3cm)
Inner Pack
Height12.8" (32.5cm)
Length12.8" (32.5cm)
Width10.39" (26.4cm)
Inner Pack Qty.3
Unit Package Dimensions
Height3.27" (8.3cm)
Length12.6" (32cm)
Width5.31" (13.5cm)
Master Carton
Height11.22"
Width13.78"
Depth12.6"
Master Carton Qty.6
Weight
Master Carton Wt.19.47lb (8.83kg)
Inner Pack Wt.9.06lb (4.11kg)
Unit Pack Wt.2.6lb (1.18kg)
Unit Wt.0.8lb (0.36kg)
