4 Port Desktop KVMs

4-Port Dual-Link DVI KVMP Switch with 7.1 Audio and Cables (TAA Compliant)

4-Port DVI EOL TAA Compliant
MPN: GCS1784

UPC: 881317006226

This product is EOL and is no longer being sold.
Sale price$499.95

IOGEAR's 4-port Dual-Link DVI KVMP switch with 7.1 audio supports high-end 3D graphics support (NVIDIA® 3D Vision Ready), compatible with most gaming keyboards. The integrated 4-port USB 2.0 hub allows for peripheral sharing. Experience up to 2560 x 1600 video resolution on four computers and share multiple USB peripherals from a single keyboard, monitor, and mouse console.

4-Port Dual-Link DVI KVMP Switch with 7.1 Audio and Cables (TAA Compliant)
4-Port Dual-Link DVI KVMP Switch with 7.1 Audio and Cables (TAA Compliant) Sale price$499.95

4-Port Dual-Link DVI KVMP with 7.1 Audio

IOGEAR's 4-port Dual-Link DVI KVMP switch with 7.1 audio supports high-end 3D graphics support (NVIDIA® 3D Vision Ready), compatible with most gaming keyboards. The integrated 4-port USB 2.0 hub allows for peripheral sharing. Experience up to 2560 x 1600 video resolution on four computers and share multiple USB peripherals from a single keyboard, monitor, and mouse console.

EDID Support

This 4-Port DVI KVM switch features IOGEAR's DynaSync™* technology, enabling the KVMP to read and remember the monitor's optimal display (EDID) parameters and refresh rate. This is a critical function in today's graphic intense applications where large wide screen displays (up to 30") are required.

Convenient Switching Method

Switching between computers can be done in three convenient ways:

  1. Push button port selection located on the unit's front panel
  2. "Hotkey" combinations entered from the keyboard
  3. Mouse** port switching

High Video Resolution Solution

This powerful 4-Port Dual-Link DVI KVMP will increase efficiency and save equipment cost for applications where ultra-high video resolution, large or widescreen monitors are required such as:

  • CAD (Computer Aided Design) and CAM (Computer Aided Manufacturing)
  • Desktop Publishing / Graphic Design / Video Editing
  • Medical / Surgical / Diagnostic Displays
  • And High-End Gaming, where high and ultra-high video resolution is demanded.

4K UHD Resolution

Achieve 3840 x 2160 @30Hz 4K UHD Resolution with this Dual-Link DVI KVM Switch using IOGEAR™ 4K HDMI to DVI-D Converter Cable GHDDVIC4K3. With this reversible 4K cable, you may use 4K source and project to 4K monitor, without the need to upgrade your Dual-Link DVI KVM switch setup.

Increase Efficiency from One Workstation

The patented asynchronous switching allows the user to independently switch applications between the connected computers. You can run one application on one computer while running another application on the other. Moreover, the integrated 4-port USB 2.0 hub is available for each computer to share multiple peripherals connected to the hub or via an external powered USB 2.0 hub. Access to such peripherals is performed on a one-at-a-time basis.

7.1 Surround Sound

Share 7.1 surround sound audio between four computers. Connect powered desktop speakers for stereo sound and a single microphone for audio input/output to each computer.

Secure Access and Control

This 4-port KVM also offers a cost-effective solution to increase security by allowing users to switch between the Internet connected PC and an Intranet connected PC.


*IOGEAR™ DynaSync provides the EDID support for Windows 7

**Only on 3-button wheel mouse

  • One console controls four computers
  • 2-port USB 2.0 peripheral hub [ backward compatible with USB 1.1 ]
  • Share a 7.1 audio surround sound system
  • Asynchronous hotkey switching between KVM focus, USB peripheral, and Audio ports
  • Switching "Beep", mutable via hotkeys
  • Complete keyboard and mouse emulation for error free booting and real-time switching
  • IOGEAR's Display Emulation Technology reads and remembers the monitor's parameters (EDID) so the user doesn't experience delays or change in video resolution when switching between or booting computers1/li>
  • Supports MAC keyboards and special keys
  • Maximum video resolutions:
  • Full support for DDC, DDC2, and DDC2B monitors
  • Firmware upgradeable
  • DVI compatible, HDCP Compliant
  • Out-of-Box solution including all cabling

1IOGEAR's DynaSync provides EDID support for Windows
2Use with IOGEAR's 4K cable GHDDVIC4K3, 4K sources, and 4K monitor

Console:

  • 1 DVI display
  • 1 standard 104 key wired USB keyboard
  • 1 standard 2 or 3 button USB mouse

Computers:

  • 1 DVI port
  • 1 USB port

Operating Systems:

  • Windows® XP, Windows Vista®, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10
  • Mac OS 9 to 10.x
  • Oracle® Solaris
  • Linux®, Unix and other USB supported systems*

*Additional drivers and support may be needed
**IOGEAR’s DynaSync provides the EDID support for Windows(R) 7

  • 1 x 4-Port Dual-Link DVI KVMP Switch with 7.1 Audio
  • 4 x Dual-Link DVI-D KVM Cable
  • 4 x 7.1 Audio Cable
  • 1 x Firmware Upgrade Cable
  • 1 x Power Adapter
  • 1 x Installation Guide
  • 1 x Warranty Card

Need more help with this product? Visit IOGEAR Knowledge Base

Distributor Part #
Ingram V27626
DH GCS1784
Synnex 2270385
SKU ECCN
GCS1784 EAR99
FunctionGCS1784
Computer Connections
Direct4
Port SelectionHotkey, Push Button
Console Connectors
Mouse1 x USB Type A Female
Keyboard1 x USB Type A Female
Monitor1 x Dual Link DVI-I Female
Flash ROM Upgrade1 x 4-conductor 3.5mm Jack (Black)
Connectors-Audio(console)
Center/Subwoofer1 x Mini Stereo Jack Female (Orange)
Line In1 x Mini Stereo Jack Female (Blue)
Line Out1 x Mini Stereo Jack Female (Green)
Microphone1 x Mini Stereo Jack Female (Pink)
Rear Speaker Out1 x Mini Stereo Jack Female (Black)
Side Speaker Out1 x Mini Stereo Jack Female (Grey)
CPU Connectors
Keyboard & Mouse4 x USB Type B Female
Monitor4 x Dual Link DVI-I Female
Connectors-Audio(CPU)
Center/Subwoofer1 x Mini Stereo Jack Female (Orange)
Line In1 x Mini Stereo Jack Female (Blue)
Line Out1 x Mini Stereo Jack Female (Green)
Microphone1 x Mini Stereo Jack Female (Pink)
Rear Speaker Out1 x Mini Stereo Jack Female (Black)
Side Speaker Out1 x Mini Stereo Jack Female (Grey)
Peripheral Sharing2 x USB 2.0 Type A Female
LEDs
Selected4 (Orange)
USB Peripherals4 (Green)
Emulation
KeyboardUSB
MouseUSB
Video Resolution4K UHD: 3840 x 2160 @30Hz (use with GHDDVIC4K3, 4K sources, and 4K monitors); DVI-D: 2560x1600 @60Hz (Dual Link); 1920x1200 @60Hz (Single Link); 3840x2400 @13Hz (Single Link - with special monitors only); DVI-A: 2048x1536; DDC2B
Scan Interval1-99 sec (5 sec default)
Power
VoltageDC 5.3V
Amps2.4A
Environment
Operation Temperature0~50?C
Storage Temperature-20~60?C
Humidity0~80% RH, Non-condensing
Housing
CaseMetal
DimensionsGCS1784
Unit Dimensions
Width17in.
Height2.25in.
Depth6.125in.
Unit Package Dimensions
Width22.125in.
Height9.625in.
Depth8.25in.
Master Carton
Width22.875in.
Height10.75in.
Depth25.5in.
Master Carton Qty.3
Weight
Master Carton Wt.43.4lb
Unit Pack Wt.13.6lb
Unit Wt. w/accessories10.8lb
Unit Wt.6lb.
