USB-C Travel Docks
USB-C Travel Dock with Power Delivery 3.0
Plug-N-Play
Single Monitor
USB-C
UPC: 881317515186
This product is EOL and
is no longer being sold.
USB-C Travel Dock with Power Delivery 3.0
Sale price$99.95
Regular price$99.95
Choose options
USB-C Travel Dock with Power Delivery 3.0
Sale price$99.95
Regular price$99.95
Quickly Add USB Ports
Maintain Power
Perfect Companion for Traveling Professionals
- 8-in-1 Travel-size USB-C docking station for mobile professionals
- Charge laptop & devices with up to 100W pass-through **
- Connect an HDMI display and enjoy HD audio and video resolution to 4K
- SD/MicroSD card reader/writer supports memory expansion
- 3x USB 3.0 ports; 1x BC1.2 charging port (1.5A)
- Gigabit Ethernet Data Port*
- Compatible with Thunderbolt 3 (USB-C) laptops & tablets
- Rugged aluminum housing
- Fast Role Swap provides safe operation for connected devices during power changes
- HDCP 1.4 compliant
- Works with the new USB-C iPad Pro under mirror-mode
* For initial setup,Internet may take 1-3 minutes to connect.
** Power Delivery 3.0 pass0through offers up to 100W of charging power utilizing the laptop's USB-C power adapter. USB-C power adapter not included..
** Maximum of up to 85W of power can be delivered to the laptop after deduction of 15W used by the docking station. Pass-thru power delivered to the laptop is dependent upon the capacity of your USB-C power supply. Ex. If your USB-C power supply is 60W, then the maximum power can be delivered to the laptop is 60W-15W = 45W. If your power supply is 87W, then the maximum power can be delivered to the laptop is 87W-15W= 60W.
- USB-C (Thunderbolt 3 compatible) device with DP Alt Mode support
- Windows 7/8/8.1/10/11
- Mac OS X 10.7+
- Chrome OS
- GUD3C06 x 1
- Quick Start Guide x 1
- Warranty Card x 1
Need more help with this product? Visit IOGEAR Knowledge Base
| Function | GUD3C06 |
|---|---|
| Upstream Port | |
| USB-C | USB 3.1 Gen 1 supports data and Power Delivery 3.0 |
| Downstream Port | |
| Card Reader | Supports Secure Digital v3.0 UHS-I (Ultra High Speed)?SDR12 (12.5Mbyte/s)/SDR25(25Mbyte/s)/SDR50(50Mbyte/s)/DDR50(50Mbyte/s)/SDR104(104Mbyte/s) |
| Ethernet | Supports 10/100 /1000Mbps |
| HDMI | HDMI 1.4 compliant, resolution up to 4Kx2K @30Hz |
| USB-A | 3x USB 3.0, 1 port supports BC1.2 fast charging |
| USB-C | 1x USB 3.1 supports data transfer or Power Delivery 3.0 |
| Power | |
| Power Delivery Pass-Thru | PD 3.0 / 100W (A total of up to 85W can be charged to the laptop after deduction of max 15W used by the dock) |
| Data Rate | Up to 5Gbps |
| Video Resolution | Up to 4K@30Hz, with 16:9 ratio |
| Environment | |
| Humidity | 10% to 90 % RH (no condensation) |
| Operation Temperature | 0? to +45? |
| Operating System Requirements | |
| Mac | Mac OS X 10.7+ |
| Windows | Windows 7 / 8 / 8.1 / 10 |
| Dimensions | GUD3C06 |
|---|---|
| Unit Dimensions | |
| Height | 2" (5.2cm) |
| Length | 4.1" (10.5cm) + tethered USB-C connector 5.35" (13.6cm) |
| Depth | 0.35" (0.9cm) |
| Inner Pack | |
| Height | 6.30" (16cm) |
| Length | 11.41" (29cm) |
| Width | 5.91" (15cm) |
| Inner Pack Qty. | 6 |
| Unit Package Dimensions | |
| Height | 5.71" (14.5cm) |
| Length | 5.31" (13.5cm) |
| Depth | 1.74" (4.4cm) |
| Master Carton | |
| Height | 12.20" (31cm) |
| Width | 13.39" (34cm) |
| Depth | 12.6" (32cm) |
| Master Carton Qty. | 24 |
| Weight | |
| Master Carton Wt. | 7 lbs (3.16kg) |
| Inner Pack Wt. | 1.8 lbs (0.82kg) |
| Unit Pack Wt. | 0.3lb (0.14kg) |
| Unit Wt. | 0.2 lb (0.09kg) |
