Video Switch
4-Port HDMI Switch with Remote and RS-232
4 Port
EOL
HDMI Switch
UPC: 881317507129
This product is EOL and
is no longer being sold.
Choose options
4-Port HDMI Switch with Remote and RS-232
Sale price$99.95
Regular price$99.95
HDMI Switch
The IOGEAR high-end 4 Port HDMI® switcher with IR and RS-232 control with support for 3D. A switching solution with 4 HDMI inputs for devices such as DVR / Set-top boxes, Blu-ray / DVD players, game consoles and media servers; all connected to one HDTV display.
Applications: Home - Boardroom - Education - House of Worship - Sports Bar
It supports Full HD 1080p with deep color accompanied with Dolby TrueHD and DTS HD Master Audio for exceptional high-end quality. Includes a built-in serial port with RS-232 bi-directional capabilities along with intuitive front panel pushbutton and IR remote control.
Need more help with this product? Visit IOGEAR Knowledge Base
| Function | GHSW8141 |
|---|---|
| Video Resolution | 480i, 480p, 720p, 1080i, 1080p |
| Video connections | |
| Input | 4 x Female HDMI Type A 19 Pin |
| Output | 1 x Female HDMI Type A 19 Pin |
| Connectors | |
| Video Input | Female HDMI Type A 19 Pin |
| Video Output | Female HDMI Type A 19 Pin |
| RS-232 | 1 |
| LEDs | |
| Input | 4 |
| Power On | 1 |
| Data Rate | Up to 2.25Gbps |
| Environment | |
| Operation Temperature | 32F~122F (0C~50C) |
| Storage Temperature | -4F~140F (-20C~60C) |
| Humidity | 0-80% RH (Non Condensing) |
| Power Consumption | 3 Watts (max) |
| Power Adapter | DC5V 1A |
| Power | |
| Voltage | DC 5V |
| Amps | 1A |
| Housing | |
| Case | Metal |
| Dimensions | GHSW8141 |
|---|---|
| Unit Dimensions | |
| Width | 8" |
| Height | 1" |
| Depth | 3" |
| Unit Package Dimensions | |
| Width | 10.5" |
| Height | 3.75" |
| Depth | 5.25" |
| Master Carton | |
| Width | 12" |
| Height | 11" |
| Depth | 11.25" |
| Master Carton Qty. | 6 |
| Weight | |
| Master Carton Wt. | 13.6 LB |
| Unit Pack Wt. | 2.1 LB |
| Unit Wt. | 1.05 LB |
