MiniView™ Micro USB PLUS KVM Switch with audio and cables
UPC: 881317005137
Choose options
Introducing the two port MiniView™ Micro USB PLUS KVM switch from IOGEAR - the simplest way to simultaneously run and share audio among two computers with a single USB keyboard, monitor and USB mouse. This self-powered KVM switch features the unique USB sniffing technology for USB mouse and keyboard emulation to ensure smooth operation, as well as support for Plug-n-Play monitors and most wheel mice.
Patented VSE Video Signal Enhancement® technology provides rich, 32-bit color at resolutions up to 2048 x 1536. Another big plus is the MiniView's capability to provide audio support, it allows you to share your multimedia speakers among the two connected computers. This switch also offers multi-platform support; it is compatible with Windows* and Mac computers as well as Sun Solaris workstations. IOGEAR delivered a huge breakthrough in KVM operation to Mac and Sun users by enabling functionality for the special keys on these systems. When using a PC keyboard, a special set of hot keys are designed to emulate the special keys on Mac and Sun machines. With 6' long KVM cables molded into the MiniView Micro USB PLUS, all you need to do is to plug it into your computers and you've got a complete KVM solution from IOGEAR.
*IOGEAR™ DynaSync provides the EDID support for Windows 7
- Use one USB keyboard, monitor and USB mouse to control two USB computers
- 6' long molded-in cables to simplify setup
- Share your multimedia speakers among the two connected computers
- Full support for Mac and Sun systems
- Supports special keys on Mac and Sun keyboards
- Port selection through convenient Hot Keys
- USB sniffing technology allows complete USB mouse and keyboard emulation for error-free boot-up
- Plug-n-Play monitor support
- Support video resolutions up to 2048 x 1536
- No software required
- Built in AutoScan mode
- LEDs allow for easy status monitoring
- 3 Year Limited Warranty
- Computers with a USB connection and HDDB15 VGA connection
- Windows® 7, 8.1, 10, 11
- Mac OS® X 9.0+
- Sun Solaris work station
- Linux, UNIX and other USB supported systems**
- Audio: Only support 2-piece, powered speakers systems
*IOGEAR’s Display Emulation Technology provides the EDID support for Windows 7
**Additional drivers and support may be needed
- 1 MiniView Micro USB PLUS 2 Port KVM Switch
- 1 User Manual
- 1 Quick Start Guide
- 1 Warranty Registration Card
Need more help with this product? Visit IOGEAR Knowledge Base
| Function | GCS632UW6 |
|---|---|
| CPU Connectors | |
| Monitor | 2 x HDB15 Male |
| Audio | 2 x stereo speaker |
| Keyboard & Mouse | 2 x USB Type A |
| Console Connectors | |
| Mouse | 1 x USB Type A |
| Keyboard | 1 x USB Type A |
| Monitor | 1 x HDB15 Female |
| Audio | 1 x stereo speaker |
| Cable Length | 6 ft. (1.83 m.) |
| Cable Connections | |
| Input | USB |
| Output | USB |
| CPU or KVM Connection | USB |
| Dimensions | GCS632UW6 |
|---|---|
| POP Information | |
| 10'' Peg Hook | 4 |
| Unit Dimensions | |
| Height | 1in. ( 2.54 cm) |
| Depth | 2.25in. ( 5.7 cm) |
| Inner Pack | |
| Height | 10.25 in. ( 26 cm) |
| Length | 9 in. ( 22.8 cm) |
| Width | 7 in. (17.8 cm) |
| Inner Pack Qty. | 3 |
| Unit Package Dimensions | |
| Height | 9.75 in. (24.765 cm.) |
| Width | 6.75 in. (16.51 cm.) |
| Depth | 2.75 in. (6.985 cm.) |
| Master Carton | |
| Height | 11.125 in. ( 28.25cm) |
| Width | 14.50 in. ( 36.83 cm) |
| Depth | 18.5 in. ( 47 cm ) |
| Master Carton Qty. | 12 |
| Weight | |
| Master Carton Wt. | 19 lbs. ( 8.6 kg) |
| Inner Pack Wt. | 4.5 lbs ( 2 kg) |
| Unit Pack Wt. | 1.4 lbs. ( 0.635 kg) |
| Unit Wt. | 0.9 Lbs. (0.405 kg.) |
