2-Port Cable KVMs

2-Port DisplayPort KVM

Name: 2-Port DisplayPort KVM
Brand: IOGEAR
SKU: GCS62DP
Price: 149.95 USD
Availability: InStock

2-Port Cable KVM DisplayPort

MPN: GCS62DP

UPC: 881317513960

$149.95

IOGEAR's 2-Port DisplayPort KVM switch with audio and DisplayPort 1.2 connections break revolutionary new ground in KVM functionality by combining advanced Cinema 4K Video and USB 2.0 technology.

2-Port DisplayPort KVM

$149.95

Switch Between 2 DisplayPort Computers

The GCS62DP offers the most efficient and affordable way to switch between your two DisplayPort computers and control them with one monitor, one keyboard and one mouse.

Included Remote Port Selector for Easy Port Switching

Included push button style remote port selector with 6ft cable provides most easy and flexible way for port switching and cable management.

Optimal Resolution to Get Things Done

The simple, yet robust 2-Port DisplayPort KVM is designed with incredible DisplayPort 1.2 technology and high-definition resolutions up to 4K resolutions 4096 x 2160 @ 60Hz.

Control 2 computers using a single keyboard, mouse, and DisplayPort video console
DisplayPort 1.2 Compliant, HDCP Compliant
Computer selection via console selection button, hotkeys, and USB mouse¹
Superior video quality – up to 4K Cinema (4096 x 2160 @ 60Hz)
Multiplatform support – Windows®, Mac OS®, Linux®
Compatible with widescreen LCD monitors
Power-on detection – if either of the connected computers is powered off, the GCS62DP will automatically switch to the other computer
Independent switching of the KVM, USB, and 2.1 channel audio focus
Supports 7.1 HD audio through DisplayPort playback²
Supports multimedia keyboards, wireless keyboards and mice
Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
Mac keyboard support and emulation
USB 2.0 mouse port can be used for USB hubs and USB peripheral sharing³
Bus-Powered
Firmware upgradable
All cables included

Note:
[1] Mouse port switching is only supported under mouse emulation mode and by USB 3-key wheel mice.
[2] HD audio through DisplayPort cannot be switched independently.
[3] This feature may require an extra power adapter to be connected to the USB hub and that the GCS62DP's Mouse Emulation Mode be disabled

Console
DisplayPort compatible monitor
Standard 104 key wired USB keyboard
Standard 2 or 3 button wired USB mouse
Microphone and speakers (optional)

Computer
DisplayPort port
Type A USB port
Audio ports (optional)

Operating System
Windows® 7, Windows® 8.1, Windows® 10, Windows® 11
Mac OS® X 10.7 +

*Use with video adapter may change performance

1 x GCS62DP
2 x DisplayPort Cable (6ft.)
2 x USB 2.0 A to B Cable (6ft.)
2 x 3.5mm Audio Cable (6ft.)
1 x Port Selection Remote
1 x Quick Start Guide
1 x Warranty Card

GCS62DP Quick Start Guide Download

GCS62DP Firmware V12.112 Download

Need more help with this product? Visit IOGEAR Knowledge Base

Function	GCS62DP
Computer Connections
Direct	2
Port Selection	Hotkeys, Mouse, or Port Selection Remote
Console Connectors
Monitor	DisplayPort 1.2
Mouse	1 x USB 2.0 Type A Female
Keyboard	1 x USB 2.0 Type A Female
Audio	1 x 3.5mm Mini Stereo Jack Female
CPU Connectors
Audio	2 x 3.5mm Mini Stereo Jack Female
Monitor	2 x DisplayPort 1.2
Keyboard & Mouse	2 x USB 2.0 Type B Female
Video Resolution	up to 4096 x 2160 @60Hz

Dimensions	GCS62DP
POP Information
10'' Peg Hook	3
6'' Peg Hook	2
Unit Dimensions
Height	1.06" (2.69cm)
Depth	3.75" (9.53cm)
Length	3.75" (9.53cm)
Unit Package Dimensions
Width	6.43" (16.33cm)
Height	9.25" (23.5cm)
Depth	2.81" (7.13cm)
Master Carton
Width	16" (40.64cm)
Height	7.375" (18.733cm)
Depth	9.375" (23.813cm)
Master Carton Qty.	6
Weight
Master Carton Wt.	9.85lb (4.46kg)
Unit Pack Wt.	1.5lb (0.7kg)
Unit Wt.	0.25lb (0.12kg)

3 Year Limited Warranty
